Description
Integrated 4×4 Enterprise AP
The UDM delivers the requisite high‐performance Wi‐Fi and fits into high‐density environments as part of the overall enterprise network.
Integrated Security Gateway
The UDM offers advanced firewall policies and persistent threat management to act as an Intrusion Prevention System (IPS) and Intrusion Detection System (IDS).
Integrated Cloud Key
The UniFi Network Controller can provision UniFi devices, map out networks, and quickly manage system traffic.
Integrated Gigabit Switch
The UDM provides a managed 4-port Gigabit switch so you can easily add network storage or wired client devices.
High‐performance antenna : 802.11ac Wave 2 4×4 MU-MIMO for 5 GHz and 802.11n for 2.4 GHz
Processor : ARM Cortex-A57 Quad-Core at 1.7 GHz
Advanced security : Gateway with IPS and DPI
Ethernet ports : 5 GbE Ports: 1 WAN and 4 LAN
Vlan support : Security and Traffic Management
Secure communications : VPN Server
QOS : Enterprise VoIP
Dimensions : Ø 110 x 184.2 mm (Ø 4.33 x 7.25″)
Weight : 1.05 kg (2.32 lb)
Networking Interfaces : (4) LAN 10/100/1000 RJ45 Ports, (1) WAN 10/100/1000 RJ45 Port
Buttons : Reset
IDS/IPS Throughput : 850 Mbps
Processor : Arm Cortex-A57 Quad-Core at 1.7 GHz
System Memory : 2 GB DDR RAM
On-Board Flash Storage : 16 GB
Maximum Power Consumption : 26W
Supported Voltage Range : 100 – 240VAC
Power Method : AC Power Cord
Power Supply : Internal AC/DC Power Adapter (24V, 0.6A, 100 – 240VAC)
Power Save : Supported
Beamforming : Supported
Antenna : (1) Dual-Band, Quad-Polarity Antenna
Wi-Fi Standards : 802.11 a/b/g/n/ac/ac-wave2
Wireless Security : WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES), 802.11w/PMF
BSSID : Up to 8 per Radio
Operating Temperature : -10 to 45° C (14 to 113° F)
Operating Humidity : 5 to 95% Noncondensing
Certifications : CE, FCC, IC
