Description
Powerful Wireless Features
Access Point PtMP airMAX Mixed Mode
airMAX ac Protocol Support
Long-Range Point-to-Point (PtP) Link Mode
Selectable Channel Width : PtP: 10/20/30/40/50/60/80 MHz | PtMP: 10/20/30/40 MHz
Automatic Channel Selection
Transmit Power Control: Automatic/Manual
Automatic Distance Selection (ACK Timing)
Strongest WPA2 Security
Usability Enhancements
airMagic® Channel Selection Tool
Dynamic Configuration Changes
Instant Input Validation
HTML5 Technology
Optimization for Mobile Devices
Detailed Device Statistics
Comprehensive Array of Diagnostic Tools, including RF Diagnostics and airView® Spectrum Analyzer
Dimensions : 257 x 84 x 41 mm (10.12 x 3.31 x 1.61″) Without Mount
Dimensions : 257 x 84 x 30 mm (10.12 x 3.31 x 1.18″) With Mount
Weight : 233 g (8.22) oz
Power Supply : 24V, 0.5A Gigabit PoE Supply (Included)
Max. Power Consumption : 9W
Power Method : 802.3af Alternative A (Pairs 1, 2+; 3, 6 Return) | 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Gain : 16 dBi
Networking Interface : (2) 10/100/1000 Mbps Ethernet Ports
Channel Bandwidths : 10/20/30/40/50/60/80 MHz
Processor Specs : Atheros MIPS 74Kc, 560 MHz
Memory : 64 MB DDR2
Cross-pol Isolation : 20 dB Minimum
Max. VSWR : 1.6:1
Beamwidth : 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
Polarization : Dual Linear
Enclosure : UV Resistant Polycarbonate
LEDs : (1) Power, Eth1, Eth2; (1) Signal Strength
Mounting : Pole-Mount (Kit Included)
Operating Temperature : -40 to 70° C (-40 to 158° F)
Operating Humidity : 5 to 95% Noncondensing
RoHS Compliance : Yes
ESD/EMP Protection : ±24kV Contact/Air
Shock & Vibration : ETSI300-019-1.4
Certifications : CE, FCC, IC
