Description
FEATURES
GIGABIT PERFORMANCE
Minimize transfer times and stream high-bandwidth files to connected devices without interference
PLUG-AND-PLAY CONVENIENCE
Instantly extend your office network with a quick and easy installation.
QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION
Prioritize traffic to particular devices or activities & maintain mission-critical data throughput regardless of network congestion
AUTO-SENSING PORTS
Automatically optimize speed for each connected device.
TECHNICAL SPECS
- Model Name:
LGS116 - Network Standards:
- IEEE 802.3
- IEEE 802.3u
- IEEE 802.3x
- IEEE 802.3ab
- IEEE 802.3az
- Ports:
16 Gigabit Ethernet (10/100/1000) Ports - LEDs:
Link, speed, and activity indicators - Performance:
- Full line rate and forwarding rate of 64B frame at:
- 1.488Mpps for 1000M port
- 0.1488Mpps for 100M port
- 0.01488Mpps for 10M port
- MAC Address Table Size:
8K - Bandwidth:
32 Gbps (non-blocking) - Fans:
None - Minimum System Requirements:
Connected devices need Ethernet connectivity and Ethernet cables - Dimensions (LxWxH):
288 x 102 x 26 mm - Weight:
0.703 kg - Power:
12 VDC, 1 A - Power Consumption:
2.36W/8.01W
- Power Consumption:
2.66 W / 9.32 W - Power Saving:
Cable connected detection, sleep mode - Power Supply:
External - Operating Temperature:
0–50°C - Storage Temperature:
-40–70°C - Operating Humidity:
10–90% (non-condensing) - Storage Humidity:
10–90% (non-condensing) - Quality Of Service:
802.1p and DSCP - Regulatory Compliance:
FCC Class B, CE - Warranty and Support:
5 Year Warranty
