SFP-10G-USR Overview

Huawei SFP-10G-USR is a 10GBase-USR Optical Transceiver. It’s a Multi-mode Module.

Part number : 02310MNW
Version support : Supported in V100R002C00 and later versions
Transceiver form factor : SFP+
Transmission speed : 10GE
Center wavelength (nm) : 850
Standards compliance : 10GBASE-USR
Connector type : LC
Type of the end face of the fiber ceramic ferrule : PC or UPC

Applicable cable and maximum transmission distance

Multimode fiber (OM2) (with diameter of 50 μm): 30 m
Multimode fiber (OM3) (with diameter of 50 μm): 100 m
Multimode fiber (OM4) (with diameter of 50 μm): 150 m

Modal bandwidth

Multimode fiber (OM2): 500 MHz*km
Multimode fiber (OM3): 2000 MHz*km
Multimode fiber (OM4): 4700 MHz*km

Transmit power (dBm) : -7.3 to -1
Maximum receiver sensitivity (dBm) : -10.7
Overload power (dBm) : 0.5
Extinction ratio (dB) : ≥ 3
Operating temperature : 0°C to 70°C
