Description

SFP-10G-iLR Overview

Optical Transceiver,SFP+,9.8G,Single-mode Module 1310nm,1.4km,LC.

Basic Information

Module name SFP-10G-iLR
Part Number 02311BJJ
Model SFP-10G-iLR
Form factor SFP+
Application standard 10GBASE-iLR (non-standard)
Connector type LC
Optical fiber type SMF
Working case temperature [°C(°F)] -40°C to +85°C (-40°F to +185°F)
Transmission rate [bit/s] 10 Gbit/s
Target transmission distance [km] Single-mode fiber: 1.4 km

Transmitter Optical Characteristics

Center wavelength [nm] 1310 nm
Maximum Tx optical power [dBm] 0.5 dBm
Minimum Tx optical power [dBm] -8.2 dBm
Minimum extinction ratio [dB] 3.5 dB

Receiver Optical Characteristics

Rx sensitivity [dBm] -14.4 dBm
Overload power [dBm] 0.5 dBm
