Description
QSFP28-100G-SR4
Part number : 02311GBW
Version support : Supported in V200R001C00 and later versions
Transceiver form factor : QSFP28
Transmission speed : 100GE
Center wavelength (nm) : 850
Standards compliance : 100GBASE-SR4
Connector type : MPO
Type of the end face of the fiber ceramic ferrule : PC or UPC
Applicable cable and maximum transmission distance
8-strand or 12-strand, type B, female connector
Multimode fiber (OM3) (with diameter of 50 μm): 70 m
Multimode fiber (OM4) (with diameter of 50 μm): 100 m
Modal bandwidth
Multimode fiber (OM3): 2000 MHz*km
Multimode fiber (OM4): 4700 MHz*km
Transmit power (dBm) : -8.4 to +2.4
Maximum receiver sensitivity (dBm) : -8.5
Overload power (dBm) : 2.4
Extinction ratio (dB) : ≥ 2
Operating temperature : 0°C to 70°C
