Description

OSX010000

Huawei OSX010000 is a 10G Optical Transceiver. It’s a Single-mode Module.

Module name OSX010000
Part Number 02318170
Model OSX010000
Form factor SFP+
Application standard 10GBASE-LR
Connector type LC
Optical fiber type SMF
Working case temperature [°C(°F)] 0°C to 70°C (32°F to 158°F)
Transmission rate [bit/s] 10 Gbit/s
Target transmission distance [km] Single-mode fiber: 10 km

Transmitter Optical Characteristics

Center wavelength [nm] 1310 nm
Maximum Tx optical power [dBm] 0.5 dBm
Minimum Tx optical power [dBm] -8.2 dBm
Minimum extinction ratio [dB] 3.5 dB

Receiver Optical Characteristics

Rx sensitivity [dBm] -12.6 dBm
Overload power [dBm] 0.5 dBm
