Description
No Installation Needed
TA300 is ready to be used straight out of the box without any hassle of wiring. Just place it on a surface, and it’s ready to go!
Easy Data Management
Uploading and downloading of data is possible with TA300. Data management is done simply with a USB cable. Get ready to Plug & Play!
Sturdy and Stable
TA300 has a wide base for stability, and is designed to be placed on a flat surface. This makes it suitable to be used in almost any businesses and centres.
Value for Money
This model was designed to be economical so that you are able to implement FingerTec solutions at a lower cost. We believe that when it comes to security, there should be no compromise.
Battery Powered
TA300 has a built in battery that can last up to 5 hours under normal usage. No need to worry about power cuts or lack of power supply points anymore!
Fast Paced & Versatile
TA300 gives you an option of identity verification through fingerprint scanning or password. On top of that, fingerprint verification is done within a second!
Small in Looks, Big in Storage
TA300 may look small and compact, but it is able to store 500 fingerprint templates, and 30000 transactions at one go. This means less frequent downloading of data for you.
Manage Your Data Easily
Administration is easy with the bundled software! FingerTec’s TCMS V2 software allows you to generate reports, monitor attendance and integrate FingerTec with a third party system.
SPECIFICATIONS |
|
| MODEL | TA300 |
| SURFACE FINISHING | Acrylonitrile butadiene styrene (ABS) |
| TYPE OF SCANNER | Non coated optical scanner |
| MICROPROCESSOR | 400 MHz |
| MEMORY | 8 MB flash memory |
| ALGORITHM | BioBridge VX 9.0 / VX10.0 |
| PRODUCT DIMENSION (L X W X H), mm | 160 x 120 x 127 |
| STORAGE | |
| Fingerprint templates | 1500 |
| Transactions | 50000 |
| ENROLLMENT & VERIFICATION | |
| Methods | Fingerprint (1:1, 1:N) & password (Optional RFID card) |
| Recommended fingerprint per user ID | 2 |
| Fingerprint placement | Any angle |
| Verification time (sec) | < 1 |
| FAR (%) | < 0.001 |
| FRR (%) | < 1 |
| CARD TECHNOLOGY | |
| RFID: 64-bit, 125kHz, RF output power (EN300-330) | Made to order |
| MIFARE: MFIS50/S70, 13.56MHz | Make to order |
| HID: HID 1325, 26-bit, 125kHz | Make to order |
| COMMUNICATIONS | |
| Method | USB cable / connection |
| OPERATING ENVIRONMENT | |
| Temperature (°C) | 0 ~ 45 |
| Humidity (%) | 20 ~ 80 |
| Power input | DC 5V 800mA |
| MULTIMEDIA | |
| Voice | Yes |
| Display | Black and white |
| Internal backup battery | Yes (DC 5V, 1300mAh) |
| VOICE / DISPLAY LANGUAGE (TERMINAL) | English (Standard), Arabic, Indonesian, Chinese Traditional / Simplified, Cantonese, Vietnamese, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Persian. |
| Other languages are available upon request. | |
| SOFTWARE LANGUAGE | English, Arabic, Arabic (Kuwait), Chinese Traditional / Simplified, Persian, French, German, Indonesian, Italian, Korean, Lithuanian, Malay, Polish, Portuguese, Portuguese (Brazil), Russian, Spanish, Thai, Turkish, Vietnamese |
