Description
5 Unlocking Credentials
Unlock doors using fingerprint, mechanical key, password, card or your smartphone’s Bluetooth connection.
3 User Group Types
Gain better access control management with FingerTec Smart Lock User Group Types: Admins, Regular Users and Temporary Users.
User Capacity
Register as many users within i-TimeTec App and i-Neighbour App through a smartphone.
Normally Open Type
This particular setting caters for offices or areas with regular visitor access. Thereby, reducing instances resulting in entrances being ‘bottlenecked’
Optimal Battery Life
Only 4 AA alkaline batteries are required to operate over 6000 accesses. Hence, approximately a year of use before you are faced with the low-battery warning indication.
Reversible Left-Right Open
Changing the handle from left to right and vice versa only requires a latch change.
Emergency Override Key
In case of an emergency like losing a smartphone. TL-400B comes with a concealed override key for accessing the door.
Downloadable App
Android and iOS Apps for i-TimeTec and i-Neighbour are available for those who prefer to use a smartphone of door access.
Surface finishing : Zinc alloy
type of scanner/antena : Optical fingerprint scanner
algorithm : Biobridge VX 10.0
resolution of scanner (dpi) : 560
Thickness of door, mm : 30-38 (optional), 50-65 (optional)
Door latch type : Mortise design with single latch and two deadbolts
Inner lock switch : Yes
Fingerprint templates : 100
Password : 100
Card : 100
Bluetooth : Unlimited users for i-Security App & i-Neighbour App
Fingerprint : 1: N
Recommended fingerprint per user ID : 2
Fingerprint placement : Any angles
Verification time (sec) : < 1
FAR (%) : < 0.0001
FRR (%) : < 0.1
Communication : Bluetooth 4.0
Voice guidance : Yes
Temperature (°C) : - 20 to – 55
Humidity (%) : 20 ~ 80
Power input : 4 x1.5v AA battery for 6000 operations
Power consumption – static (µA) : < 35
Power consumption – activity (mA) : < 135
Power consumption – driving (mA) : < 200
Antistatic voltage (V) : > 1500
Low battery warning voltage (V) : < 4.5
