Description
GOLD Series
500-1000+ For Video Surveillance Systems
Fibrenetix GOLD-Series – A Class Of Its Own
When considering the market for 500, or even 1000+ mega-pixel cameras, Fibrenetix GOLD-Series of servers and storage expansion is in a class of its own.
The GOLD-Series comes with built in 3D-scalabitly, offering true scalability; Performance, Capacity and High Availability. The ultra-density formfactor offers a TCO (total cost of ownership), which is hard to beat in the surveillance industry. The GOLD-Series power consumption per TB and AC cooling costs are up to 20% lower than comparable standard servers.
The ultra-density formfactor of the GOLD-Series provides an extremely small footprint in an IT server room. In a single 19” rackmount cabinet, 20x high performance, dual processor GOLD servers, with 7 Petabytes of storage can be installed, making the GOLD-Series the market leader.
Tech Specs:
| GOLD SERVERS SERIES | MTS-412-XX |
| Product Code | MTS-41262-1681-M16-A9 |
| Processor | Intel® Xeon Scalable CPU (per node) |
| Number of CPUs | 2 |
| Memory (Min|Max) | 16GB, up to 1536GB (per node) |
| Storage Bays | 8x 2.5” Hot-Swap Storage Bays |
| Max. HDD Capacity Supported | SSD 7.6TB |
| Maximum Raw Storage Capacity | 60.8TB |
| Max Capacity – Per IP San Controler | 9.2PB |
| Hardware RAID Levels | 1, 5, 6 |
| Optional 10GBps Support | Yes |
| Network | 2x RJ-45 GbE LAN Ports |
| Graphics (Standard) | Aspeed AST2500, 64MB VRAM |
| USB Ports | 2x USB 3.0 Ports (Per Node) |
| Video Ports | 1x VGA (Per Node) |
| Hot-swap Components | HDDs, PSUs, Fans |
| Operating System | Windows® Server 2016 |
| Power Supply | 1+1 Redundant 1600W |
| Voltage | 200-240Vac, 9.5A |
| Dimensions – mm (D x W x H) | 800 x 444 x 88 (2U) |
| Net Weight | 39kgs |
| Operation Temperature | 10℃ ~ 35℃ |
| Certification | BSMI, CE, RCM, FCC(Class A) |
| Warranty Period | 3 Years |
| BTU/hr | 5470.72 |
Advantages
- Space saving – more TB per rackmount cabinet
- Fully tested with Milestone and all major VMS
- Plug&Play technology – add drives without taking the server offline
- Space and Power Efficient
Applications
Schools, Malls, Banks, Buildings, Hospitals, Factories, Oil & Gas, Aviation, Military, Government, Enterprise class, Hotels…
