Description
DP-Series: Video Analytics Servers
2 To 8 GPU Cards
GPU-Power Taking Video Analytics To The Next Level
With the increased use of CCTV cameras and density of sensors, Video analytics is a must to enable enhanced security and surveillance solutions by automatically monitoring video content.
Face recognition and Wide-Area Situational Awareness (WASA) requires LIVE and immediate Alerts to be efficient. However, previous generations of Video Analytics Servers are struggling to handle the amount of data, which is the reason for the high cost of large scale Video Analytic applications. The Fibrenetix DP-Series, supports up to 8x compatible NVIDIA cards with thousands of CUDA Cores in each GPU card. Reducing the amount of video data operators must review, and enabling a high level of monitoring for any size video system.
Numbers of required Servers are reduced dramatically and therefore cost of implementation is equally reduced.
When Server density is reduced the operator can expect considerable savings on electrical power consumption and need for A/C Server room cooling, offering the lowest cost of ownership in the industry today.
Examples For Use
- Face Recognition
- License Plate Recognition
- Airport Security
- Traffic Congestion
- Situational Awareness
- Investigation and Forensics
- Wrong way detection
- Instant Video search
Tech Specs:
| DP SERIES | DP-852-4U |
| Processor | Intel® Xeon® Gold CPUs |
| Number of CPUs | 2 |
| Memory (Min|Max) | 16GB, up to 3072GB |
| OS Storage (internal 2.5”) | 2x 240GB SSD |
| Storage Bays | 8x Hot-swap 2.5” HDD Bays |
| Max. HDD Capacity Supported | SSD 7.6TB |
| Maximum Raw Storage Capacity | 60.8TB |
| Max Capacity – Per IP San Controler | 9.2PB |
| Optional 10GBps Support | Yes (2) |
| Network | 2x 1Gbps Port Intel I350-AM2 |
| Graphics (Standard) | Aspeed AST2500, 64MB VRAM |
| Expansion Slots for GPUs | Up to 8x Double-Deck GPU Cards |
| USB Ports | 2x USB 3.0 Ports |
| Video Ports | 1x VGA |
| Operating System | Windows® Storage Server 2016 |
| Power Supply | 1+1 Redundant 1600W |
| Voltage | 200-240Vac, 9.5A |
| Dimensions – mm (D x W x H) | 798 x 439 x 175.6 (4U) |
| Net Weight | 23.5kgs |
| Operation Temperature | 10℃ ~ 35℃ |
| Certification | BSMI, CE, RCM, FCC(Class A) |
| Warranty Period | 3 Years |
| BTU/hr | 5470.72 |
Applications
Schools, Malls, Banks, Buildings, Hospitals, Factories, Oil & Gas, Aviation, Military, Government, Enterprise class, Hotels.
