Description
Only One In Its Class
The Great Dane is a unique Super Converged NVR appliance, the only one in its class within the security industry Great Dane offering Super Converged capabilities at an industry leading price performance ratio.
A Single Enclosure – An Industry First
Great Dane combines High performance recording, high capacity storage and Hardware decoding into a single enclosure, which is an industry First. The High performance recording server supports up to 900 cameras, unsurpassed storage capacity of up to 2.5PB per unit and the built-in latest hardware decoding technology allows for Play Back on multiple displays.Fibrenetix’s proven track-record of reliability and optimized video performance are visible in every aspect of the Great Dane series.
Continues Playback While Recording Without Loss
The INTEL HD 630 hardware decoder offers continues playback while recording without any frame loss or loss of CPU performance.
Applications
Schools, Malls, Banks, Buildings, Hospitals, Industry, Hospitality.
Tech Specs:
| Product Code | GD-1662-256 |
| Processor | Intel® Xeon E3 Scalable CPU |
| Number of CPUs | 1 |
| Memory (Min|Max) | 16GB, up to 256GB |
| OS Storage (internal 2.5”) | 2x 240GB SSD |
| Storage Bays | 16x Hot-swap |
| Max. HDD Capacity Supported | 18TB |
| Maximum Raw Storage Capacity | 288TB |
| Max Capacity – SAS | 4.6PB |
| Max Capacity – Per IP San Controler | 9.2PB |
| Hardware RAID Levels | 5, 6, 10, 50 & 60 |
| Optional 10GBps Support | Yes |
| Network | 2x Dual Port Gigabit |
| Graphics (Standard) | Intel HD Graphics P630 |
| USB Ports | 2x USB 3.0 – 4xUSB 2.0 |
| Video Ports | VGA, HDMI, DVI, Display Port |
| Hot-swap Components | HDDs, PSUs |
| Operating System | Windows 10, Windows Server 2016 |
| Power Supply | 2x 800W |
| Voltage | 100-127/200-240Vac |
| Dimensions – mm (D x W x H) | 740 x 444 x 132 (3U) |
| Net Weight | 23.6kgs |
| Operation Temperature | 10℃ ~ 35℃ |
| Certification | BSMI, CE, RCM, FCC(Class A) |
| Warranty Period | 3 Years |
| BTU/h | 2735.36 |
