Description
Processor
1 processor from the following product families:
Intel® Xeon® processor E3-1200 v6 product family
Intel Pentium®
Intel Core i3®
Intel Celeron®
Operating System
Microsoft® Windows Server® 2012
Microsoft Windows Server 2012 R2, x64
Microsoft® Windows Server® 2016
Red Hat® Enterprise Linux®
VMware vSphere® ESXi®
SUSE® Linux Enterprise Server®
Chassis
Tower server (5u when racked)
Rack Support
ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm.
Chipset
Intel C236
Communications
2 X 1GbE LOM
Dimensions & Weight
Height: chassis base height – 430.3 mm/17.04 in
With foot – 443.3 mm/17.45 in
With wheel – 471.3 mm/18.55 in
Width: chassis base width – 218 mm/8.58 in
With foot – 304.5 mm/11.98 in
Depth: front to rear wall (w/o bezel) – 542.2 mm/21.33 in
front to PSU handle (w/o bezel) – 578.42 mm/22.77 in
front to rear wall (with bezel) – 558.6 mm/21.99 in
front to PSU handle (with bezel) – 594.82 mm/23.41 in
Drive Bays
8 x 3.5″ bays (also supports 2.5” HDD in 3.5” hybrid drive carrier)
Device Access
8 total USB:
Rear USB: 2 x USB3.0 + 4 x USB 2.0
Front USB: 1 x USB 2.0 + 1 x USB 3.0
Embedded Hypervisor (Optional)
Hypervisor Support
Microsoft Windows Server with HyperV®
VMware vSphere ESXi®
Memory*
Architecture: Up to 2400MT/s DDR4 DIMMs
Memory Type: UDIMMs
Memory Module Sockets: 4
Maximum RAM: Up to 64GB
Management
Systems management:
IPMI 2.0 compliant
Dell OpenManage Essentials
Dell OpenManage Mobile
Dell OpenManage Power Center
Dell OpenManage Integrations:
Dell OpenManage Integration Suite for Microsoft System Center
Dell OpenManage Integration for VMware vCenter®
Dell OpenManage Connections:
HP Operations Manager
IBM Tivoli® Netcool®
CA Network and Systems Management
Dell OpenManage Plug-in for Oracle® Database Manager
Remote management:
iDRAC8 with Lifecycle Controller
iDRAC8 Express (default)
iDRAC8 Enterprise (upgrade)
8GB vFlash media (upgrade)
16GB vFlash media (upgrade)
Slots
4 slots:
1×8 PCIe 3.0 (x16 connector)
1×4 PCIe 3.0 (x8 connector)
1×4 PCIe 3.0 (x8 connector)
1×1 PCIe 3.0 (x1 connector)
Storage
2.5” SATA 7.2K
2.5” SATA SSD’s
2.5” nearline SAS 7.2K
2.5” SAS 10K HDDs
2.5” SAS 15K HDDs
3.5” Enterprise SATA 7.2K HDDs
3.5” nearline SAS 7.2K HDDs
