Description
Processor
1 processor from the following:
Intel® Xeon® E-2100 product family,
Intel Pentium®,
Intel Core i3®,
Intel Celeron®
Chassis
Form Factor: Rack (1U)
Dimensions:
Chassis width: 434.00mm (17.08)
Chassis depth: 534.50mm (21.04) (3.5 HHD config)
Note: These dimensions do not include: bezel
Chassis weight: 12.2 kg (29.98 lbs)
Bezel
Optional security bezel
Hard Drive Configuration
Up to 4 x 3.5 hot-plug SAS, SATA, or SSD*
Up to 2 x 3.5 cabled SAS, SATA, or SSD*
Memory*
DIMM Speed: Up to 2666MT/s DDR4 DIMMs
Memory Type: UDIMMs
Memory Module Slots: 4
Maximum RAM: Up to 64GB
Management
Embedded / At-the-Server
iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC RESTful API with Redfish
Consoles
OpenManage Enterprise
OpenManage Essentials
OpenManage Power Center
Mobility
OpenManage Mobile
Tools
iDRAC Service Module
OpenManage Server Administrator
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
Dell EMC RACADM CLI
IPMI Tool
OpenManage Integrations
Microsoft® System Center
VMware® vCenter™
BMC Truesight (available from BMC)
Red Hat Ansible
OpenManage Connections
Nagios Core & Nagios XI
Micro Focus Operations Manager i (OMi)
IBM Tivoli Netcool/OMNIbus
Network Controller
2 x 1GbE LOM Network Interface Controller (NIC) ports
Ports
Front:
One USB 2.0
Micro USB 2.0 compliant for iDRAC Direct
Rear:
Two USB 3.0
VGASerial connector
Internal port:
One USB 3.0
Power Supplies
Single 250W or a 450W cabled PSU
I/O Expansion Slots
2 x PCIe Gen 3.0 slots
- One x8 slot low-profile, half length with x4 slot width
- One x16 slot low-profile/full-height, half length with x8 bandwith
Supported Operating Systems
Microsoft Windows Server® with Hyper-V
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi
Citrix® XenServer®
Ubuntu Server
Certify XenServer
Storage Controllers
Internal controllers: PERC H730P, H330, HBA330 (non-RAID)
Software RAID: PERC S140
External HBAs: 12Gbps SAS HBA (non-RAID)
Boot Optimized Storage Subsystem: 2x M.2 240GB (RAID 1 or No RAID), 1x M.2 240GB (No RAID only)
Rack Support
ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).
Recommended Support
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region
Designed for the budget-conscious businesses
Enterprise-class features at prices you can afford
- Increase performance with up to 50%* higher core counts. Customers can choose a 4- or a 6-core Intel® Xeon® E-2100 processor
- Address data sets with up to four DDR4 DIMMs and with a maximum of 64GB of RAM
- Reduce operational costs with multi-vector cooling that automatically calculates and delivers the proper airflow needed for optimal cooling
