Description
Processor
2x Full AMD SP3 processor stack TDP, up to 180W, up to 32 cores per processor
Bezel
Optional LCD or Security Bezel
Chassis
Depth:
67.73 cm(26.67 in)
Width:
43.4 cm(17.09 in)
Height:
8.68 cm(3.42 in)
Drive Bays
Front Drive Bays:
Up to 24 x 2.5” SATA/SAS/NVMe or up to 12x 3.5” SAS/SATA HDD
Mid Drive Bays:
Up to 4 x 2.5” NVMe or up to 4x 3.5” SAS/SATA HDD
Rear Drive Bay:
Up to 4 x 2.5” or 2 x 3.5” SAS/SATA HDD
Embedded Management
iDRAC9 with Lifecycle Controller (no power capping)
iDRAC Direct
iDRAC REST API with Redfish support
Quick Sync 2 BLE/wireless module
Integrations and Connections
Microsoft® System Center
VMware® vCenter™
BMC Software (available from BMC)
Nagios Core and Nagios XI
HPE Operations Manager i (OMi)
I/O and Ports
Network daughter card options:
4 x 1GE or 2 x 10GE + 2 x 1GE or 4 x 10GE or 2 x 25GE
Front ports:
VGA, 2 x USB 2.0, dedicated iDRAC Direct Micro-USB
Rear Ports:
VGA, Serial, 2 x USB 3.0, dedicated iDRAC network port
Video Card:
VGA
Riser Options:
Up to 8 x Gen3 slots; up to 6 x16 lanes
Memory*
32 DDR4 DIMM slots, Supports RDIMM, LRDIMM
OpenManage Software
OpenManage Enterprise
OpenManage Essentials
OpenManage Mobile
Power Supplies
Titanium 750W, Platinum 495W, 750W, 1600W, 1100W, and 2000W
336-380DC 1100W addition for China and Japan only
48VDC 1100W, 380HVDC 1100W, 240HVDC 750W
Recommended Support
Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.
Supported Operating Systems
Microsoft Windows Server® 2016
Red Hat® Enterprise Linux 7.4
VMware® vSphere 2016 U1 (ESXi 6.5 U1)
Microsoft Windows Server® 2012 R2
Storage Controllers
Internal Controllers:
PERC H330, H730p, H740p, HBA330
Boot Optimized Storage System:
HW RAID 2 x M.2 + Internal USB + Internal Dual SD Module
External PERC (RAID):
H840
External HBAs (non-RAID):
12Gbps SAS HBA
12Gbps PERC9 or 10 series, PCIe PERC x8 slot
Security
TPM 1.2/2.0 optional
Digitally signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown
Secure Erase
Scale-up performance for extreme computing
The PowerEdge R7425 platform delivers outstanding TCO for data analytics, hybrid cloud and scale up software-defined deployments. Easily add extreme memory and storage capacity for low latency, data intensive workloads. With up to 64 cores, 128 PCIe lanes, and up to 32 DIMMs, the R7425 provides the balance of compute to I/O that gives you the freedom to take on challenging data intensive projects.
Optimized for:
- HPC
- VDI cloud client computing
- Database/in-line analytics
- Scale up software-defined environment
