Description
Key features and benefits:
Maximum of access points:
- 50
- Recommended up to 25
11ac
- 20, 40, 80 MHz channels
- 4×4 Downlink (DL) MU-MIMO with four spatial streams, up to 1733 Mbps
Indicators
- Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors
System memory
- 1GB MB DRAM, 256 MB flash
Warranty
- Cisco Business Limited lifetime hardware warranty for CBW240AC
- Free software updates, no service contract required
Authentication and security
- 802.11r and 802.11i
- Segmentation via VLANs (up to 16)
Ethernet ports
- Authentication with 802.1X or MAC filtered
- Dynamic VLAN or per port
Specifications
Connectivity technology: Wireless AC
Maximum active WLAN clients: 16
Antenna: 2 x internal PIFA
Number of access points: supported per cluster None
Data transfer rate: Up to 2333 Mbps
Network and transport protocol: DHCP, Bonjour
Multiple input, multiple output (MIMO): 2 x 2:2 for 2.4 Ghz and 5 GHz or 1×1 on both 2.4 Ghz and 5 GHz
Number of radios: 1
Status indicators: One LED power, WLAN, LAN
Frequency band: 2.4 GHz and 5 GHz
Interfaces: 1 Ethernet 10BASE-T/100BASE-TX/1000BASE-T; RJ-45
Mounting kit: No, desktop only
Data link protocol: IEEE 802.11a/b/g/n, IEEE 802.11ac
