Description
Product Details
High performance
Cisco Business 110 Series switches deliver the performance you need to run your business applications, including bandwidth-intensive cloud applications and video services, and to avoid slow and sluggish networks. They support Gigabit Ethernet speeds, unlocking a new level of capacity and performance in your business network and letting you transfer large files in seconds.
Reduced energy costs
Cisco Business 110 Series switches are designed to help conserve energy by optimizing power use without compromising performance, which protects our environment and reduces your energy costs. In addition, they support the Energy Efficient Ethernet (IEEE 802.3az) standard, which reduces energy consumption by monitoring the amount of traffic on an active link and putting the link into a sleep state during quiet periods.
Peace of mind
Cisco Business 110 Series switches deliver the rock-solid reliability you expect from a Cisco switch. The solution has been rigorously tested to make sure of optimal uptime and performance. In addition, the limited lifetime hardware warranty provides peace of mind.
Specifications
Capacity in millions of packets per second (mpps) (64-byte packets): 35.7 mpps
Switching capacity in gigabits per second (Gbps): 48 Gbps
Total system ports: 24 Gigabit Ethernet
RJ-45 ports: 24 Gigabit Ethernet
Packet Buffer: 2 Mbit
Unit dimensions (W x D x H): 279 x 170 x 44 mm (11 x 6.7 x 1.73 in)
General
Head-of-line (HOL) blocking: HOL blocking prevention
MAC table: 2K addresses for CBS110-5T-D, 8K addresses for all other models
Jumbo frame: 9216 bytes
Quality of Service (QoS): 802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR)
Loop detection: Helps discover loops in the network to avoid broadcast storms
Cable diagnostics: Quickly identify and troubleshoot network cable faults and/or shorts
Media-dependent interface: Automatic Media Dependent Interface (MDI) and MDI crossover (MDI-X)
Standards: IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet
Hardware
LEDs: Power, link/activity (cable diagnostics, loop detection), Gigabit, * PoE, * Max PoE. *if present
Cabling type: Category 5e or better
Mounting options: Desktop, wall-mount or rack mount
Physical security lock: Kensington lock slot
Flash: 16 MB for CBS110-16T, CBS110-16PP, 8 MB for CBS110-24T, CBS110-24PP
CPU: 400 MHz ARM for CBS110-16T, CBS110-16PP, CBS110-24T, CBS110-24PP
CPU memory: 128 MB for CBS110-16T, CBS110-16PP, 64 MB for CBS110-24T, CBS110-24PP
