Description
Features
Robust industrial design
- Built for harsh environments and temperature ranges (-40°C to +75°C)
- Fanless, convection-cooled with no moving parts for extended durability
- Hardened for vibration, shock and surge, and electrical noise immunity
- Complies with multi-industry specifications for automation, ITS, and substation environments
- Improves uptime, performance, and safety of industrial systems and equipment
- Covers a wide range of Power over Ethernet (PoE) application requirements
- Alarm I/O for monitoring and signaling to external equipment
Full Gigabit Ethernet interfaces
- Provides secure access for new high-speed applications in the industrial space
- Packs up to 10 ports of GE – 2×1 Gigabit Small Form-Factor Pluggable (SFP) uplinks, plus 8×1 Gigabit copper RJ45 downlink ports (with PoE+ or non PoE) in a small form-factor base system
- Connects high-speed wireless access points (802.11n, 802.11ac)
- Enables High-Definition (HD) IP cameras and Programmable Logic Controllers (PLC)
- Delivers multiple rings and redundant ring topologies for new network configurations
- Extends geographical scalability where longer-distance connectivity is required
High-density industrial Power over Ethernet (PoE)
- Supports up to 8 PoE/PoE+ ports [Power budget – 240W]
- Controls costs by limiting wiring, distribution panels, and circuit breakers
- Reduces equipment needs, thus requiring less space and reducing heat dissipation
- Enables ready-to-use PoE devices, such as IP phones, cameras, and wireless access points
User-friendly GUI, called WebUI
- Allows easy configuration and monitoring
- Eliminates the need for more complex terminal emulation programs
- Reduces the cost of deployment
SwapDrive, a zero-configuration replacement
- True zero-configuration and simple switch replacement in the event of a failure
- No networking expertise required
- Helps ensure fast recover
Specifications
Brand: Cisco
Management: Layer 3 Managed
Mounting: DIN Rail
Number of Ports: 10
Type of Ports: Copper RJ45 Copper RJ45(POE) SFP
Speed: GE
Max Operating Temperature: 70 °C
Min Operating Temperature: -40 °C
Input Voltage: 12 VDC 24 VDC 48 VDC 110 VDC 220 VDC 110 VAC 220 VAC 240 VAC
Jumbo Frames: Yes
TSN Support: No
Redundant Power: Yes
