Cisco Business 350 Series Smart Switches CBS350-16FP-2G in UAE, Dubai

Cisco Business 350 Series Smart Switches CBS350-16FP-2G

With the CBS350-16FP-2G 16-Port Gigabit PoE+ Compliant Managed Switch with SFP+, you can quickly expand your business’s network capacity to support powered devices such as IP security cameras, wireless access points, VoIP phones, and more. This managed rackmount switch has 16 PoE+ compliant Gigabit Ethernet ports and a 240W power budget to power compatible devices. Two Gigabit SFP+ ports are also available for high-speed fibre connections. Secure connections, clear communications, and link aggregation to create up to eight groups of 16 ports for multi-Gig connections to compatible devices are among its extensive Layer 2 and Layer 3 features. Its 20 Gb/s switching capacity and forwarding rate of 26.78 Mpps contribute to smooth and reliable data transfers. Configure and monitor the Cisco CBS350-16FP-2G and its connected devices using the Cisco Business Dashboard portal and mobile app. The fanless design reduces power consumption while allowing the switch to run quietly in the background.

Key Features

16 x PoE+ Gigabit Ports
2 x 1GbE SFP Ports
20 Gb/s Switching Capacity
26.78 Mpps Forwarding Rate

Description

Specifications

Interfaces
Ports : 16 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+
2 x 10/100/1000 Mb/s Gigabit SFP
1 x Micro-USB (Console)

Protocols
Layer Services Supported: Layer 2 Support, Layer 3 Support
Supported Protocols: Head-of-Line (HOL) Blocking
IGMP Snooping
IPv4
IPv6
Link Aggregation
MAC Filtering
Port Mirroring
RADIUS
SNMPv1
SNMPv2c
SNMPv3
Queuing: Strict Priority, Weighted Round Robin (WRR)
Jumbo Frames: Support 9000 Bytes
MAC Address Table: Size 16K
Multicast Groups: 2000
VLAN IDs: 4094

Security
Security Features: DoS Attack Prevention
RADIUS Authentication
Storm Control
Access Control List : 024
IP Interfaces: 128
Static Routes: 990
SNMP Support: 1, 2c, 3

Standards
RFC : 4330
Supported IEEE Standards: 802.1ab, 802.1d, 802.1q/p, 802.1s, 802.1w, 802.1x, 802.3, 802.3ab, 802.3ad, 802.3af, 802.3an, 802.3at, 802.3az, 802.3u, 802.3x, 802.3z

Performance
Forwarding Rate: 26.78 Mpps
Switching Bandwidth: 36 Gb/s
Priority Queues: 8
Packet Buffer: 1.5 MB

Computer
Flash Memory: 256 MB
Processor: 800 MHz ARM
Memory: 512 MB
OS Compatibility: Windows
macOS
Linux

Electrical
Power Draw: 284.00 W (Max)
AC Input: Power 100 to 240 VAC, 50 / 60 Hz
PoE Power Budget: 240 W
PoE per Port: 30 W

Environmental
Operating Temperature: 23 to 122°F / -5 to 50°C
Operating Humidity: 10 to 90%
Storage Temperature: -13 to 158°F / -25 to 70°C
Storage Humidity: 10 to 90%

General
Cooling System: Passive
Mean Time Between Failures (MTBF): 698,220 Hours
Indicator Lights: Link/Activity, PoE, Speed, System
Rack Form Factor: 1 RU
Dimensions: 12.1 x 10.6 x 1.7″ / 308 x 268 x 44 mm
Weight: 5.49 lb / 2.49 kg

Additional information

Brand	Cisco

Cisco Business 350 Series Smart Switches CBS350-16FP-2G
