Description
Management features
Switch type Managed
Quality of Service (QoS) support Yes
Multicast support Yes
Web-based management Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 8
Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)
Combo SFP ports quantity 2
Console port RJ-45
Networking
Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Flow control support Yes
Port mirroring Yes
DHCP server Yes
IGMP snooping Yes
Spanning tree protocol Yes
10G support No
Data transmission
Switching capacity 5.6 Gbit/s
MAC address table 8000 entries
Number of VLANs 256
Protocols
Management protocols SNMP v1/v2c/v3
Design
Rack mounting No
Colour of product Grey
LED indicators Activity,Link,Power
Housing material Metal
International Protection (IP) code IP30
Certification UL, cUL, CE, FCC, RoHS, WEEE
Performance
Stackable No
Firmware upgradeable Yes
Packet buffer memory 0.13 MB
Buffer size 4096 KB
Mean time between failures (MTBF) 272761 h
Power
Output voltage 24 V
Output current 1 A
Power consumption (typical) 8.064 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) -10 – 65 °C
Storage temperature (T-T) -40 – 85 °C
Operating relative humidity (H-H) 5 – 95 %
Storage relative humidity (H-H) 5 – 95 %
Weight & dimensions
Width 72 mm
Depth 115 mm
Height 152 mm
Weight 1340 g
Packaging data
User guide Yes
